Thickness: 0.13-0.80 mm
Width: Max 1550 mm
Coating Thickness: Top: 10-25 μm Back: 3-20 μm
Surface Treatment: Protective Film, Wrinkle, Matt, Metal Embossed and Printed
We Offer:PPGI, PPGL, Home Appliance, Printed and Self-Cleaning Steel, Color Coated Aluminium/Stainless
Sample images of Printed Steel:
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
思泰恩-印花图片
Coating Types

Polyester

PE

PE has good adhesion with galvanized steel, steel with PE can be easy to modelling, it is cheap and suitable for multiple products. Many different options can be chosen from color and gloss. In the normal condition, it has 5-8 years of corrosion protection, whereas the product life can decrease once in the highly polluted area

Silicon Modified Polyester

SMP

SMP has a longer life, but with higher costs and lower cohesion & formability, its anti-corrosion period up to 10-12 years

High Durability Polyester

HDP

High molecular resin and fewer polymer branches, forming a stable bond, not easy to be photo-decomposed. This paint has high color retention, UV resistance, outdoor durability and anti-chalking performance, it has 15 years of corrosion protection

Special Reinforced Polyester

SRP

It has excellent resistance to resin degradation in long-term sunshine and high-temperature environment, excellent durability but high hardness, lasting 15-20 years of anti-corrosion

Polyvinyli -dene Fluoride

PVDF

High performance in anti-corrosion and color retention. It is the highest standard paint material in building construction. Lasting 20-25 years anti-corrosion, but with high cost. There are limited color to choose from when using this paint, and only low gloss paint can be used

Paint Suppliers
思泰恩
思泰恩
思泰恩
思泰恩
思泰恩
55% Al | 43.5% Zn | 1.5% Si
Thickness: 0.13-0.60 mm
Width: Max 1250 mm
Zinc Coating: 30-250 gsm
Surface Treatment: Chromating, Transparent/Colored Anti-Finger Print (AFP) and Oiled
Application: Building wall, Electrical cabinet, Home appliance, Automobile, Raw material of prepainted steel
思泰恩

Blue AFP

思泰恩

Green AFP

思泰恩

Golden AFP

思泰恩
Heat Resistance:resistant to high temperatures of 500-600°C
Corrosion Resistance: life cycle is 2-5 times longer than galvanized steel
High Heat Reflection:reflection coefficient is twice than galvanized steel, reducing indoor temperature in summer
Condition

Indoor Area

Suburbs Area

Downtown and Factory Area

Costal Area

Al-Zinc Weight

AZ70 or AZ100

AZ150 or AZ100 with color coating

AZ150 with color coating

AZ180+ with color coating

When zinc is used for sacrificial protection on trimming, scratches and coating scratches, aluminum will form an insoluble oxide layer on the outside of the steel plate as barrier protection function. The weight of the coating is the most important factor for corrosion resistance. The greater the thickness of the coating, the better the corrosion resistance
思泰恩
Corrugated steel sheet is processed to various waves by rolling and bending. It is widely used in architecture, storage, warehouse, building wall and intrinsic & extrinsic decoration. Having characteristic of light weight, high strength, rich color, convenient and quick construction, earthquake resistance, fire prevention, rainproof, maintenance-free
Our Range of Roofing Sheets Includes:
思泰恩
Box Profile galvanized steel roofing sheets – ideal for roofing or cladding industrial, commercial or domestic buildings for a modern look. These roofing sheets are available with the choice of thicknesses 0.13-0.6 mm; Protective film, Wrinkle, Matt, Metal Embossed and Printed finishes and in all RAL. colors.
思泰恩
Corrugated Galvanized steel roofing sheets – ideal for roofing or cladding agricultural, equestrian or domestic buildings for a more traditional look. These roofing sheets are available in thicknesses 0.13-0.6 mm; Protective film, Wrinkle, Matt, Metal Embossed and Printed finishes and in all RAL. colors.
思泰恩
Tile Effect and Pan Tile galvanized steel roofing sheets – give the appearance of an actual tiled roof, ideal for roofing all types of buildings however look exceptional on log cabins, summer houses, garages and domestic buildings. These roofing sheets are available in thickness 0.13-0.6 mm; Protective film, Wrinkle, Matt, Metal Embossed and Printed finishes and in all RAL. colors.

Cases

思泰恩

Warehouse in Yenişehir

Location:Turkey

Storage Centre in Cairo

Location:Egypt
